6PCV-04-006
TE Connectivity / Buchanan BrandConn Barrier Strip 4 POS 9.52mm Solder ST Thru-Hole 25A .. see full description
- RoHS Compliant
- Pack Packaging
- Set Notification
-
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Buchanan Brand
Part No:
6PCV-04-006
RoHS:
Yes
HTS:
8536904000
COO:
CN
ECCN:
EAR99
Package Type:
Pack
Type:
Barrier Strip
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
9.52 mm
Number of Circuits:
4
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Wire Size:
12-22 AWG
Operating Temperature:
105(Max) °C
The 6PCV-04-006 is a 4-position 1-row Tri-barrier Strip with tin-plated copper alloy contacts and thermoplastic housing. The 6-1437652-7 1-level black terminal block has printed circuit pin bottom terminations, zinc chromate-plated steel 6-32 screw and combo Phillips-slot screw head. The tri-barrier block help contain stray or frayed wire ends. This helps prevent electrical shorts-not only between positions on the same block, but also between other components immediately adjacent to the block. With today's high density PCB designs, this has become an increasingly important feature.
Back barriers to safeguard field wiring
Fast wiring-backed-out wire-ready screws
Interrupted thread designed to prevent screws from falling out Standoffs allow flux and solvents to drain during cleaning Open bottom with standoffs style
Direct (all positions filled) mounting style
Vertical mounting angle
UL94V-0 Flammability rating
Applications
Industrial, Automation & Process Control, HVAC, Power Management, Security
Product Highlights:
- Barrier Strip
- Tri-Barrier Block Series
- Base Style = Raised
- 9.53 mm Centerline
- Number of Levels = Single
Search Keywords:
6PCV04006
IN STOCK:
355
Can Ship immediately
Minimum Order:
10
Factory Lead-Time
24 Weeks
Price (CAD)
Quantity
Unit Price
Ext. Price
10
$2.777
$27.770
210
$1.751
$367.710
420
$1.743
$732.060
630
$1.734
$1,092.420
1,050
$1.655
$1,737.750
2,520
$1.627
$4,100.040
5,040
$1.619
$8,159.760
7,560
+
$1.610
$12,171.600
Click for Quote
Please Note:
Item may be subject to tariff fee if shipping within the United States
DOWNLOADS
Datasheet
