796634-3
TE Connectivity / Amp Brand3 Position Terminal Block Plug, Female Sockets 0.200" (5.08mm) 180° Free Hanging (In-Line) .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Amp Brand
Part No:
796634-3
RoHS:
Yes
HTS:
8536904000
COO:
IT
ECCN:
EAR99
Package Type:
Box
Type:
Eurostyle Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
5.08 mm
Number of Circuits:
3
Maximum Voltage Rating:
300 VAC
Maximum Current Rating:
15/Contact A
Wire Size:
12-30 AWG
Operating Temperature:
N/A
The 796634-3 is a 3-position 1 row 5.08mm pluggable Terminal Block with tin-plated phosphor bronze contact, nickel-plated brass screw, polyamide 6.6 green housing. Plug connector, right angle mounting, through hole contact mount, screw wire connection method, M3 screw and 30 to 16AWG wire range.
Side wire entry angle Number of Positions: 3 Position
Pitch: 5.08 mm
Connection Method: Screw
Current Rating: 15 A
Voltage Rating: 300 V
Wire Gauge Range: 30 AWG to 12 AWG
Color: Green
Contact Plating: Tin
Housing Material: Polyamide (PA)
Mounting Angle: Right
Applications
Industrial
Product Highlights:
- Connector
- Connector Type = Plug
- Housing Color = Green
- Not Stacked
- Without Threaded Flange
Search Keywords:
7966343
IN STOCK:
8,579
Can Ship immediately
Minimum Order:
10
Factory Lead-Time
9 Weeks
Price (CAD)
Quantity
Unit Price
Ext. Price
10
$2.689
$26.890
200
$1.454
$290.800
400
$1.439
$575.600
600
$1.389
$833.400
1,000
$1.357
$1,357.000
2,600
$1.347
$3,502.200
5,000
$1.340
$6,700.000
7,600
+
$1.334
$10,138.400
Click for Quote
