5748676-3 by TE Connectivity / Amp Brand
DATA SHEET

5748676-3

TE Connectivity / Amp Brand

This Cable Clamp Kit with Grommets from TE features a die cast shield and comes with 6 grommets per set. The kit has a shell size of 16.26 mm and a cable O.D. range of 6.48 mm to 11.94 mm. All parts are packaged unassembled and jackscrews must be purchased separately. The cable clamp kit, like all parts from TE, is RoHS compliant. .. see full description

  • RoHS Compliant
  • Bag Packaging
  • Accessories
  • Set Notification
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Amp Brand
Part No:
5748676-3
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Package Type:
Bag
Type:
Backshell/Cable Clamp
Shell Size:
3
Angular Function:
180 °
Operating Temperature:
N/A
Connector Type:
Connector D-Subminiature
Dimension:
53.08 x 48.76 x 17.27 mm
The TE Connectivity / AMP Cable Clamp Kit with Grommets (part 5748676-3) is designed to securely hold cables in place while providing protection and strain relief. With a die cast shield and included grommets, this kit ensures a reliable and durable solution. The cable clamp kit has a shell size of 16.26 mm and is compatible with cables with an outer diameter range of 6.48 mm to 11.94 mm. Please note that the parts are packaged unassembled and jackscrews must be purchased separately. As with all TE products, this cable clamp kit is RoHS compliant, ensuring it meets environmental and safety standards.
Product Highlights:
  • Backshell/Cable Clamp
  • Cable Clamp Type = Two-Piece RFI/EMI Shield
  • 180° Cable Exit Angle
  • Cable Insulation Diameter = 6.48 - 11.94 mm
  • Number of Positions = 25
Search Keywords:
57486763
IN STOCK: 21,710
Can Ship immediately
Factory Lead-Time
6 Weeks
Enter Quantity
Price (CAD)
Quantity
Unit Price
Ext. Price
1
$17.095
$17.095
10
$11.387
$113.870
25
$11.103
$277.575
50
$9.893
$494.650
100
$9.533
$953.300
250
$9.400
$2,350.000
500 +
$9.324
$4,662.000
Click for Quote
