5747846-4
TE Connectivity / Amp Brand25 Position D-Sub Receptacle, Female Sockets Connector .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Amp Brand
Part No:
5747846-4
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Package Type:
Tray
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
3
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
N/A
The 5747846-4 is a 25-way 2-row Right Angle PCB D-sub Receptacle with tin over nickel plated brass boardlock, 4-40 UNC threaded inserts and gold-plated phosphor bronze contacts. This HD20 series connector comes with tin-plated steel shell, black thermoplastic housing and through hole mount.
UL94V-0 Flammability rating. Number of Rows: 2 Row
Shell Size: 3 (B)
Contact Plating: Gold
Gender: Female
Type: Receptacle
Shell Material: Steel
Shell Plating: Tin
Applications
Industrial
Product Highlights:
- Number of Positions = 25
- Receptacle
- PCB Mount Angle = Right Angle
- Product Series = HD 20
- With Mating Connector Lock
Search Keywords:
57478464
IN STOCK:
5,845
Can Ship immediately
On Order:
2,600
can ship 8/15/24
Minimum Order:
5
Factory Lead-Time
2 Weeks
Price (CAD)
Quantity
Unit Price
Ext. Price
5
$5.923
$29.615
65
$3.350
$217.750
130
$3.275
$425.750
260
$3.260
$847.600
520
$3.244
$1,686.880
1,040
$3.230
$3,359.200
2,535
$3.215
$8,150.025
5,005
+
$3.201
$16,021.005
