5747844-3
TE Connectivity / Amp BrandD Sub Connector - DB9 - Size 1 - 9 Contacts - Receptacle - Solder - Right Angle - Front Metal Shell - AMPLIMITE HD-20 Series. .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Amp Brand
Part No:
5747844-3
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Package Type:
Tray
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
The 5747844-3 is a 9-position standard D-sub Plug with phosphor bronze duplex plated contacts with gold flash on mating end, tin on solder cup with entire contact nickel under-plated, thermoplastic inserts and steel plated shell.
Product Highlights:
- Number of Positions = 9
- Receptacle
- PCB Mount Angle = Right Angle
- Product Series = HD 20
- With Mating Connector Lock
Search Keywords:
57478443
IN STOCK:
1,745
Ships today, if you order in
Minimum Order:
5
Factory Lead-Time
3 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$3.079
$15.395
50
$1.793
$89.650
130
$1.785
$232.050
260
$1.767
$459.420
520
$1.758
$914.160
1,040
$1.750
$1,820.000
2,600
$1.741
$4,526.600
5,070
+
$1.732
$8,781.240
Click for Quote
