1658615-3
TE Connectivity / Amp BrandD Sub Connector - DB15 - 15 Contacts - Plug - IDC / IDT - DA - Amplimite HDF-20 Series - Plastic Body. .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Amp Brand
Part No:
1658615-3
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
IDT
Shell Size:
2
Number of Contacts:
15
Contact Plating:
Gold Over Palladium Nickel,Gold Over Nickel
Operating Temperature:
-55 to 105 °C
The 1658615-3 Amplimite HDF-20 series low-profile Sub-miniature D Connectors for round conductor flat ribbon cable. It has phosphor bronze duplex plated pin contact with gold on mating end, bright tin on termination end with entire contact under-plated nickel, steel, tin or tin plated front shell and thermoplastic housing. The contacts accept 28AWG solid and stranded and 26AWG solid and stranded round conductor flat ribbon cable on 0.05-inch centres.
Product Highlights:
- Connector
- Product Series = HDF-20 (Ribbon Cable)
- Number of Positions = 15
- Plug
- With Contacts
Search Keywords:
16586153
IN STOCK:
909
Can Ship immediately
Minimum Order:
40
Multiple:
40
Factory Lead-Time
8 Weeks
Price (CAD)
Quantity
Unit Price
Ext. Price
40
$4.636
$185.440
80
$3.902
$312.160
120
$3.804
$456.480
280
$3.698
$1,035.440
520
$3.624
$1,884.480
1,000
$3.595
$3,595.000
2,520
$3.571
$8,998.920
5,000
+
$3.543
$17,715.000
Click for Quote
Please Note:
Item may be subject to tariff fee if shipping within the United States
