1-1658621-0
TE Connectivity / Amp Brand50 Position Rectangular Receptacle Connector IDC Gold 26-28 AWG .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Amp Brand
Part No:
1-1658621-0
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Package Type:
Tube
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
50
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C
The 1-1658621-0 is a 50-position 2-row vertical wire-to-board Ribbon Cable Pin Header with gold-plated phosphor bronze contacts and black UL94V-0 rated thermoplastic housing. Novo receptacles offer a dual contact interface with all normal force created by metal-to-metal contact. This provides a higher degree of contact reliability. Contacts mate with 0.642mm or round posts with 6.22mm maximum and 4.45mm minimum lengths. The Novo tuning fork contact offers a military-approved design.
Insulation displacement contacts for fast, economical mass terminations
Contact design provides uniform latching of contacts and housing with connector cover
Accepts wire size range 28 to 26AWG (0.08 to 0.15mm²), solid or stranded
Snap-on strain relief and choice of pull loops available
One-step termination with Novo tooling
Applications
Defence, Military & Aerospace
Product Highlights:
- Connector Type = NOVO
- Number of Positions = 50
- Receptacle
- Mating Polarization Method = Center & Military
- With Mating Polarization
Search Keywords:
116586210
IN STOCK:
1,782
Can Ship immediately
Minimum Order:
50
Multiple:
50
Factory Lead-Time
15 Weeks
Price (CAD)
Quantity
Unit Price
Ext. Price
1
$3.360
$3.360
50
$3.055
$152.750
100
$2.935
$293.500
250
$2.905
$726.250
500
$2.818
$1,409.000
1,000
$2.760
$2,760.000
2,500
$2.701
$6,752.500
5,000
$2.688
$13,440.000
7,500
+
$2.675
$20,062.500
Click for Quote
Please Note:
Item may be subject to tariff fee if shipping within the United States
