2866776 by Phoenix Contact
DATA SHEET

2866776

Phoenix Contact

AC/DC Power Supply Single-OUT 24V 20A 480W Medical .. see full description

  • RoHS Compliant
  • Box Packaging
  • Accessories
  • Set Notification
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
2866776
RoHS:
Yes
HTS:
8504407012
COO:
TH
ECCN:
EAR99
Package Type:
Box
Type:
Switching
Style:
DIN Rail
AC Input Voltage:
N/A
Number of Outputs:
1
Output Voltage:
24 V
Maximum Output Current:
20 A
Maximum Output Power:
480 W
Input Connector Type:
Screw Terminal Block
Dimension:
125 x 90 x 130 mm
The QUINT-PS/1AC/24DC/20 is a 1-phase primary-switched Power Supply with SFB technology. Compact power supply units of the new QUINT POWER generation maximize the availability of your system. Even the standard power circuit-breakers can be tripped reliably and quickly with the SFB technology (Selective Fuse breaking Technology) and six times the nominal current for 12ms. Defective current paths are disconnected selectively, the defect is limited and the important system parts remain in operation. A comprehensive diagnostics is carried out by continuously monitoring the output voltage and current. This preventive function monitoring visualizes the critical operating modes and reports them to the control unit before an error occurs. Quick Tripping of Standard Power Circuit breakers with Dynamic SFB Technology Power Reserve Reliable Starting of Difficult Loads with Static POWER BOOST Power Reserve Preventive Function Monitoring Can be used World wide High degree of operational safety due to high MTBF >500000h, Long mains buffering times Applications Power Management
Search Keywords:
2866776
IN STOCK: 59
Can Ship immediately
Manufacturer Stock:
817   can ship 7/22/24
Factory Lead-Time
11 Weeks can ship 9/23/24
Enter Quantity
Price (CAD)
Quantity
Unit Price
Ext. Price
1
$563.082
$563.082
5
$546.189
$2,730.945
10
$529.800
$5,298.000
30 +
$513.904
$15,417.120
