2320018
Phoenix ContactPrimary-switched MINI DC/DC converter for DIN rail mounting - input: 1-phase - output: 5 - 15 V DC/2 A .. see full description
- RoHS Compliant
- Set Notification
-
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
2320018
RoHS:
Yes
HTS:
8504407001
COO:
CN
ECCN:
EAR99
Input Voltage:
10 to 32 V
Number of Outputs:
1
Output Voltage:
12 V
Output Current:
2 A
Output Power:
24 W
Mounting:
DIN Rail
Type:
Step Down
Dimension:
107 x 22.5 x 99 mm
Output Type:
Fixed
Family:
2320018
2320018 is a mini DC/DC converter which alter the voltage level, regenerate the voltage at the end of long cables or enable the creation of independent supply systems by means of electrical isolation. It has a nominal input voltage range of 12 to 24 VDC, nominal output voltage of 12VDC, nominal output current of 2A and efficiency of 88% or higher. The product can be mounted in horizontal DIN rail, and can also be connected in series or parallel. Connection at input and output is through M3 pluggable screw connection. Product's dimensions are 22.5mm x 99mm x 107mm (wxhxd).
Search Keywords:
2320018
IN STOCK:
14
Ships today, if you order in
Factory Lead-Time
5 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$254.534
$254.534
3
$250.558
$751.674
5
$242.143
$1,210.715
10
$237.364
$2,373.640
25
+
$228.351
$5,708.775
Click for Quote
DOWNLOADS
Datasheet
