1933215 by Phoenix Contact
DATA SHEET

1933215

Phoenix Contact

Pin strip - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 1.5 mm² - number of positions: 5 - pitch: 5 mm - color: black - contact surface: Tin - mounting: THR soldering - pin layout: Linear pinning - solder pin [P]: 3.5 mm - The maximum current depends on the plug used. The lower of the two current values apply for plug and pin strip. The pin strip is made of highly temperature resistant plastic and is thus suitable for the reflow process. .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1933215
RoHS:
Yes
HTS:
8536694040
COO:
SK
ECCN:
EAR99
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5 mm
Number of Contacts:
5
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A
The PHOENIX CONTACT part 1933215 is a Pin strip with a nominal current of 12 A and a rated voltage of 320 V. It has a nominal cross section of 1.5 mm² and features 5 positions with a 5 mm pitch. The pin strip is black in color and has a tin contact surface. It is designed for Through-Hole Reflow (THR) soldering and has a linear pinning layout. The solder pin measures 3.5 mm. The maximum current for the pin strip depends on the plug used, with the lower value of the two current ratings applying for both the plug and the pin strip. The pin strip is made of highly temperature resistant plastic, making it suitable for the reflow process.
Search Keywords:
1933215
IN STOCK: 3,549
Ships today, if you order in
Manufacturer Stock:
15,416   can ship 7/15/24
Minimum Order:
250
Multiple:
250
Factory Lead-Time
8 Weeks can ship 9/5/24
Enter Quantity
Price (USD)
Quantity
Unit Price
Ext. Price
250
$0.4288
$107.200
500
$0.4057
$202.850
1,000
$0.3939
$393.900
2,500
$0.3919
$979.750
5,000
$0.3900
$1,950.000
7,500
$0.3879
$2,909.250
10,000
$0.3859
$3,859.000
15,000 +
$0.3840
$5,760.000
Click for Quote
DOWNLOADS
PDF Datasheet
Request Free CAD Models
