1825501
Phoenix ContactPCB connector - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 2 - pitch: 5.08 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1825501
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Type:
Terminal Block
Mounting:
Panel Mount
Gender:
M
Termination Method:
Screw
Pitch:
5.08 mm
Number of Circuits:
2
Maximum Voltage Rating:
250 V
Maximum Current Rating:
12 A
Wire Size:
12-24 AWG
Operating Temperature:
N/A
The PHOENIX CONTACT part 1825501 is a PCB connector that is designed for efficient and reliable electrical connections. It has a nominal current rating of 12 A, making it suitable for a variety of applications. The connector's rated voltage is 320 V (III/2), ensuring safe and secure power transmission. With a nominal cross section of 2.5 mm², the connector can handle a decent amount of power while maintaining optimal performance. It features 2 positions, allowing for easy and organized wiring. The pitch of 5.08 mm ensures compatibility with various PCB layouts. The connection method is a screw connection with a tension sleeve, ensuring a secure and stable connection. The connector is color-coded in green, making it easy to identify and differentiate from other components. The contact surface is made from tin, providing excellent conductivity and resistance to corrosion. Overall, the PHOENIX CONTACT part 1825501 is a high-quality and versatile PCB connector that is suitable for a wide range of electrical applications.
Search Keywords:
1825501
IN STOCK:
816
Ships today, if you order in
Minimum Order:
5
Factory Lead-Time
5 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$5.459
$27.295
25
$4.660
$116.500
100
$4.413
$441.300
250
$4.391
$1,097.750
500
$4.369
$2,184.500
1,000
$4.347
$4,347.000
2,500
$4.325
$10,812.500
5,000
+
$4.303
$21,515.000
Click for Quote
