G6K-2P-Y-DC5
Omron ElectronicsSignal Relay 5VDC 1A DPDT (( 10mm 6.5mm 5mm)) Through Hole .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6K-2P-Y-DC5
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
10 x 6.5 x 5 mm
Termination Style:
PC Pin
Coil Current:
21.1 mA
Contact Form:
2 Form C
The G6K series surface-mounting Signal Relay with the dimensions of 5.7 x 10.6 x 9mm (W x L x H) represent a reduction of approximately 56% in mounting area compared with the OMRON G6S for higher-density mounting. The dielectric strength of 1500VAC and an impulse withstand voltage of 2500V for 2 x 10µs (conforms to North American Telcordia specifications (formerly Bellcore)). It conforms to FCC part 68 (impulse withstand voltage of 1500V for 10 x 160µs between coil and contacts and between contacts of the same polarity).
Single-winding latching models to save energy
Applications
Industrial, Signal Processing
Search Keywords:
G6K2PYDC5
IN STOCK:
1,455
Can Ship immediately
On Order:
2,000
can ship 8/28/24
Minimum Order:
10
Factory Lead-Time
34 Weeks
Price (CAD)
Quantity
Unit Price
Ext. Price
10
$4.715
$47.150
50
$4.389
$219.450
250
$3.849
$962.250
500
$3.543
$1,771.500
1,000
$3.470
$3,470.000
2,500
$3.411
$8,527.500
5,000
$3.338
$16,690.000
7,500
+
$3.322
$24,915.000
