142-0701-871 by Johnson / Cinch Connectivity Solutions
DATA SHEET

142-0701-871

Johnson / Cinch Connectivity Solutions

Conn - SMA - 0Hz to 18GHz - 50Ohm - Solder - ST - Edge Mount - RCP - Gold Over Nickel .. see full description

  • RoHS Compliant
  • Bag Packaging
  • Accessories
  • Set Notification
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-0701-871
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Package Type:
Bag
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
RCP
Mounting:
Edge Mount
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
9.52 x 17.45 x 7.92 mm
The 142-0701-871 is a straight SMA Coaxial Jack with gold-plated beryllium copper contact. It is attached to the circuit board by inserting the board edge between the legs and soldering the legs and center conductor to pads on the board. For optimum high frequency performance, the connector to circuit board transition must be adjusted for VSWR.
Search Keywords:
1420701871
IN STOCK: 4,175
Can Ship immediately
On Order:
10,000   can ship 8/5/24
Minimum Order:
25
Multiple:
25
Factory Lead-Time
8 Weeks
Enter Quantity
Price (CAD)
Quantity
Unit Price
Ext. Price
25
$9.369
$234.225
50
$8.294
$414.700
100
$8.055
$805.500
250
$7.920
$1,980.000
500
$7.860
$3,930.000
1,000
$7.801
$7,801.000
2,500
$7.740
$19,350.000
5,000 +
$7.696
$38,480.000
Click for Quote
Please Note: Item may be subject to tariff fee if shipping within the United States
