BZ-7RT04 by Honeywell
DATA SHEET

BZ-7RT04

Honeywell

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), No Electrical Rating, Pin Plunger, Highest Operating Force in BZ Series, Binding Head Combination Screw Termination with Integral Lock Washers, Mounting Holes will Accept Pins or Screws, No Approvals, Military Part Number M8805/1-008 .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BZ-7RT04
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Plunger
Contact Rating @ Voltage:
15@115VAC A
Maximum Movement Differential:
0.13 mm
Operating Force:
7.78 N
Termination Style:
Screw
Dimension:
49.28 x 17.45 x 25.78 mm
Body Orientation:
Straight
IP Rating:
N/A
The HONEYWELL BZ-7RT04 is a premium large basic switch from the MICRO SWITCH„¢ BZ Series. It is a single pole double throw (SPDT) switch with no electrical rating. The switch features a pin plunger, offering a high operating force that is unmatched in the BZ Series. It is equipped with binding head combination screw termination with integral lock washers for secure and reliable connections. The mounting holes of the switch are designed to accept both pins and screws, providing flexibility in installation options. This switch does not have any approvals but is a military part number M8805/1-008.
Product Highlights:
  • Accepted world-wide standard "Large Basic" switch
  • Low operating force and differential travel
  • Long mechanical life up to 20,000,000 cycles at 95% survival
  • Elongated mounting hole for easier, more accurate mounting
  • Current rating ranges from 15 A to 25 A
  • Choice of actuation, termination and operating characteristics
Potential Applications:
<ul><li>Irrigation systems</li><li>Semi-trailer trucks</li><li>Timing devices</li><li>Office equipment</li><li>Test instruments</li><li>Medical/dental equipment</li><li>HVAC equipment</li><li>Manually operated devices</li><li>Valves</li></ul>
Search Keywords:
BZ7RT04
IN STOCK: 282
Ships today, if you order in
Factory Lead-Time
11 Weeks
Enter Quantity
Price (CAD)
Quantity
Unit Price
Ext. Price
1
$54.512
$54.512
10
$40.765
$407.650
25
$36.506
$912.650
50
$35.385
$1,769.250
100
$35.043
$3,504.300
250
$34.863
$8,715.750
500 +
$34.683
$17,341.500
